Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs

Qingdao Compass Hardware Co., Ltd.
Contact Now

Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs

  • 1
  • 2

Brand Name : Compass

Model Number : 110.50

Certification : ISO 9001

Place of Origin : Qingdao, China

MOQ : 100pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, D/A, D/P

Supply Ability : 10000pcs per month

Delivery Time : 30-40days according to quantity

Packaging Details : 6pcs in a box, 10boxes in a carton.

Product name : Brushed Stainless Steel Glass Standoffs

DIA : 50mm

Material : SS304(V2A) / SS316(V4A) /SS316L

Color : Brushed or Polished

Glass thickness : 6mm-21.52mm

Type : Solid or Hollow

Contact Now

Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs

Features.

1. Type: solid or hollow ones could be supplied according needs

2. Material: V2A(SS304) or V4A(SS316) ones are available.

3. Screws: M10 or M12, could be adjusted according to the glass thickness.

4. Surface treatment could be brushd or polished.

5. Black or transparent rubbers can be supplied according to requirements.

6. Production time needs 35-45days according to final quantities.

7. Bespoke dimensions could be supplied according to requirements.

Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs

Notes.

This series could be costomized according to your drawings or samples.

These standoffs are used in glass balustrades for balcony, staircase, stairs, pool fencing in commercial and residential buildings according to needs.

General terms.

Item Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs
Material AISI3041, AISI316
Finish Satin, Mirror
Diameter 50mm
Glass thickenss 6mm-21.52mm
Packing bag + box + carton + pallet
Lead time 35-45days
Type Stianless steel polisehd glas standoffs
Transportaion

by sea, by air or by Express.

Free samples Available
Payment term T/T 30% deposit, 70% balance payed according to the documents copy.
Departure port Qingdao or according to needs
Delivery term FOB, CIF, CFR, DDU, DAP

Material

304 is the basic chromium-nickel austenitic stainless steel and has been found suitable for a wide range of applications. It is the most readily available in a variery of prodcut forms. This grade is easy to form and fabricate with excellent resistance to corrosion

316 offers more corrosion-resistance through the addition of molybdunum. This grade is desirable where the possibility of severe corrosion exists, such as heavy industrial atmospheres and marine environments.

316L is the low carbon version of 316.

C Si Mn P S Ni Cr Mo
AISI304 ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.030 8.-10.0 18.0-20.0
AISI316 ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.030 10.0-14.0 16.0-18.0 2.0-3.0
AISI316L ≤0.03 ≤1.00 ≤2.00 ≤0.035 ≤0.030 10.0-14.0 16.0-18.0 2.0-3.0

Care of Stainless Steel.

- Use pater or other protective wrapping one the surface of the stainless steel until processing is complete.

- Handle stainless steel with clean gloves or cloths to guard against stains or finger marks.

- Avoid the use of oily rags or greasy cloths when wiping the surface

- If possible, rinse with water after cleaning.

Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs

Stainless and Glass Balustrade Brushed Stainless Steel Glass Standoffs
